In the next steps, you will learn to use the Component Wizard to create the THS7001 in Multisim.

1. Step 1: Enter Initial Component Information.
2. Step 2: Enter Footprint and Package Information.
3. Step 3: Enter Symbol Information.
4. Step 4: Set Pin Parameters.
5. Step 5: Set Mapping Information between Symbol and Layout Footprint.

How do I download new components in Multisim?

To access the new components open NI Multisim, go to the Place menu and select Component. Choose the Search button and enter search criteria. For example, enter a manufacturer name or choose a product Group or Family to narrow the search to specific components.

How do I add designs to Multisim?

Complete the following steps to add another sheet to a design:

1. Select Place»Multi-page.
2. Enter the desired name and click OK.
3. Place components and wire the circuit as desired.
4. Select Place»Connectors»Off-page connector.
5. Drag the “ghost” image to the desired location and click to place the connector.

How do I download a library from Multisim?

Multisim Help

1. Select File»Open, navigate to the desired . oecl file and click Open.
2. Complete the following to set the destination for Multisim components:
3. Complete the following to set the destination for Ultiboard parts:
4. Click Import to import the selected components and parts to the selected locations.

What are virtual components in Multisim?

Virtual components These are generic devices that include a schematic symbol and a simulation model. They allow you to explore behavior without being tied to a real device. Most virtual components have parameters you can change to study the effect on your design.

How do I get components on Multisim?

If you already have Multisim (or have downloaded an evaluation version of the software) you can search for components using the following steps:

1. Open Multisim (All Programs>>National Instruments>>Circuit Design Suite X.X >>Multisim X.X) where X.X is the version number.
2. Select Place>>Component.

How do I add a page to Multisim?

To add a page to your Multisim schematic navigate to Place » Multi-page then enter the page name in the dialog box and click OK. To delete a page from your Multisim schematic navigate to Edit » Delete multi-page then select the page that you wish to delete in the dialog box and click OK.

How do I add missing components to Multisim?

Solution

1. Select Tools >> Component Wizard.
2. Determine whether you need a Layout-only or a Simulatable component.
3. Use the step-by-step instructions in the Component Wizard. Refer to Creating a Custom Component in NI Multisim for additional information.

What are the use of component toolbar in Multisim?

The Component Toolbar contains buttons that let you select components from the Multisim libraries for placement in your schematic.

How do I see node numbers in Multisim?

To show node numbers, select Sheet Properties from the Options menu. The dialog box of Figure 2-1 opens. This dialog box should be familiar as it was used in the prior exercise to set schematic colors and the like.

Where is IC 555 Multisim?

Select Tools»Circuit wizards»555 timer wizard. The 555 Timer Wizard dialog box appears. Select Astable operation from the Type drop-down list. Default settings are initially displayed.

How do I create a circuit design in Multisim?

Open Multisim by clicking on Start -> Programs -> National Instruments -> Circuit Design Suite 11.0 -> Multisim 11.0 . Create a new file with File-> New-> Design. First we need to find the components.

What do I need to learn in Multisim?

You will learn to draw and test circuits in Multisim. Note: There is a Printed Circuit Board (PCB) program called Ultiboard 11.0 for permanent Board work available. You do not need this but you can use it if you want for any final work.

How do I create a custom component in NI Multisim?

Creating a Custom Component in NI Multisim. Step 1: Enter Initial Component Information. Step 2: Enter Footprint and Package Information. Step 3: Enter Symbol Information. Step 4: Set Pin Parameters. Step 5: Set Mapping Information between Symbol and Layout Footprint.

How do I create the ths7001 in Multisim?

In the next steps, you will learn to use the Component Wizard to create the THS7001 in Multisim. Select Tools»Component Wizard from the Multisim main menu. The Component Wizard window opens. Configure this window as shown in the following figure. Figure 1.
